Crankshaft Measuring and Marking Machine

Crankshaft Measuring and Marking Machine

Product Details:

  • Color as per product
  • Usage Automatic Gauging Machines for Automobile Engine Parts
  • Application Marine Engineering, Mechanical Engineering
  • Click to view more
X

Product Specifications

  • as per product
  • Marine Engineering, Mechanical Engineering
  • Automatic Gauging Machines for Automobile Engine Parts

Trade Information

  • Western Union, Telegraphic Transfer (T/T), Letter of Credit (L/C), Cheque, Cash Advance (CA)
  • 8 Week
  • Wooden Packaging
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Technical Specification / Features :


Measurement Parameters : Diameter and straightness & Roundness of various main journals and Pin journals including , Run-outs of various mainjournals w.r.t . Centre axis and end journal axis.


Total Measurement and analysis parameters : 88 ( Linear / Form and Geometry )

Cycle time ( Measurement + marking) : 65 Sec.


  • Customised design for final inspection of crankshaft at production line all parameter measurements in single rotation.
  • PLC based fully automated cycle including loading / unloading, measurement and marking operations with assurance of highest safety POKA/YOKE.
  • Use of high precision miniature contact type inductive probs facilitated measurement of each main journal and Pin journal ( width 22 mm) in 3 Sections.
  • Measurement system consist of 70 Nos of High precision miniature inductive probes and a high resolution rotary encoder.
  • High speed data acquisition system provided for dynamic and synchronised measurement of multiple Journals simultaneously.
  • Powerful software for dynamic and synchronised data acquisition, processing of heavy data, strong mathematical algorithm for analysis of cam profile parameters, reporting , storage and data transfer .
  • On-line thermal error corrections provided to ensure highly accurate measurements at ambient atmospheric conditions.
  • Automatic gradation of every main journal in 3 grades each with 6 m steps.
  • Automatic sorting of OK / NOT OK components.
  • On-line thermal error corrections provided to ensure highly accurate measurements at ambient atmospheric conditions.
  • Data storage and sorting of measurement data of each component with unique identification and traceability of operator , date , time , Shift.
  • Measurement cycle integrated with LASER marking machine for QR code marking on OK Components . Auto generated QR code
  • Connectivity to the Local data server.
  • Industry 4.0 Compliance
